THINKCAR CE EVC201 – EV Insulation Tester, 500 V / 1000 V
619,31 €
- Insulation resistance tester for high-voltage systems in electric and hybrid vehicles
- Test voltage 500 V and 1000 V, up to 40 GΩ
- Additional voltage measurement and built-in reference resistor
- Timed, comparison and continuous measurement
- USB data transfer to the THINKCAR tablet, 2-year warranty
- Description
- Jetzt kontaktieren
- Additional information
- Reviews (0)
Description
THINKCAR CE EVC201 – insulation resistance tester for electric and hybrid vehicles
Before working on a high-voltage system, you need to be sure that the insulation between live parts and the vehicle earth is sound. The THINKCAR CE EVC201 measures exactly this insulation resistance at a test voltage of 500 V or 1000 V. It also measures voltage, offers several measuring modes and transfers readings via USB to your THINKCAR tablet.
A good fit if you …
- test high-voltage systems on electric and hybrid vehicles
- check the battery, cables, air-con compressor or drive for insulation faults
- want to document your test results
Probably not for you if you …
- are not qualified to work on high-voltage systems
- need test voltages above 1000 V
What the EVC201 can do
- Insulation resistanceMeasurement between live parts and exposed metal parts such as the housing or bodywork
- Voltage measurementAdditional voltage measuring function in the same tool
- Reference resistorBuilt-in standard resistor to check measuring accuracy
- Data transferTransfer and save readings to the THINKCAR tablet via USB
Measuring modes
- Timed measurementMeasurement over a set time interval
- Comparison measurementCompares the reading with the built-in standard resistor
- Continuous measurementUninterrupted measurement over a longer period
Technical data
| Test voltage | 500 V, 1000 V |
|---|---|
| Measuring range at 1000 V | 1 MΩ – 40 GΩ |
| Short-circuit current | < 1.8 mA |
| Display | LCD |
| Data transfer | USB to THINKCAR tablet |
| Warranty | 2 years |
Good to know
- Test when isolatedInsulation testing is carried out on a de-energised, isolated high-voltage system.
- QualificationWork on high-voltage systems must only be carried out by suitably qualified specialists.
- Complementary toolsCombined with EV diagnostic tools such as the THINKTOOL CE EVD, you get a complete toolset for the high-voltage workshop.
Questions about the EVC201?
Tell us your vehicle and your THINKCAR tool – we’re happy to help.
Questions we often get
Why do I need an insulation tester for an electric car?
To make sure there is no dangerous connection between the high-voltage components and the vehicle earth – for example before and after repairs to the battery, cables or drive.
Which test voltages does the EVC201 offer?
500 V and 1000 V. At 1000 V the measuring range is 1 MΩ to 40 GΩ.
Can I save the readings?
Yes, readings can be transferred via USB to the THINKCAR tablet and recorded there.
Additional information
| Weight | 2,9 kg |
|---|
