TOPDON PulseQ E 11 kW Wallbox with Tethered Type 2 Cable, App & RFID
446,70 €
- Wallbox with up to 11 kW, three-phase 400 V
- Tethered Type 2 charging cable, 5 m (7.5 m optional)
- App control, charging authorisation via RFID card
- IP65 for indoor and outdoor use, -35 °C to 55 °C
- CE, LVD, RED, RoHS, REACH-tested
- Description
- Jetzt kontaktieren
- Reviews (0)
Description
TOPDON PulseQ E – 11 kW wallbox with tethered Type 2 cable, app and RFID
Get home in the evening, plug in, and the car is full by morning – you don’t need a 22 kW setup for that. Most electric cars charge at a maximum of 11 kW on AC anyway. The TOPDON PulseQ E charges three-phase at up to 11 kW, has a tethered Type 2 charging cable and is controlled via app or RFID card. With IP65 protection it’s built for carports and outside walls too.
A good fit if you …
- charge an electric or plug-in hybrid vehicle with a Type 2 inlet at home
- want a wallbox with a tethered cable – no separate charging cable needed
- are mounting it outdoors and need strong protection against dust and water jets
- want to schedule charging via the app and secure access with RFID
Probably not for you if you …
- want to charge at 22 kW and your vehicle supports it – the TOPDON PulseQ AC Pro is designed for that
- want to charge on the go from different sockets – the PulseQ AC Portable is better suited
- want to connect the wallbox yourself without a qualified electrician
What the PulseQ E can do
- Charging up to 11 kWThree-phase at 400 V – right for most electric cars
- Tethered cableType 2 to IEC 62196-2, 5 m long, 7.5 m optional
- App controlStart, schedule and monitor charging sessions
- RFIDCharging only with an authorised card
- Plug and PlayPlug in the vehicle and charge without app or card – if you prefer
- Indoor and outdoorCompact housing with IP65, operation from -35 °C to 55 °C
Technical data
| Charging power | up to 11 kW |
|---|---|
| Voltage | 400 V AC, three-phase |
| Connector | Tethered Type 2 charging cable to IEC 62196-2 |
| Cable length | 5 m, 7.5 m optional |
| Protection rating | IP65 |
| Operating temperature | -35 °C to 55 °C |
| Dimensions | 310 × 215 × 95 mm |
| Weight | approx. 7–9 kg, depending on cable length |
| Authorisation | App, RFID, Plug and Play |
| Certifications | CE, LVD, RED, RoHS, REACH-tested |
Good to know
- InstallationThe wallbox must be connected by a qualified electrician.
- Grid operatorIn Germany, wallboxes must be registered with the grid operator. Up to 12 kW – so at 11 kW – no additional approval is needed. In Austria, the grid operator must also be notified. In other countries, check the local rules.
- Actual charging powerHow fast you charge also depends on the vehicle’s on-board charger. Vehicles that charge single-phase charge more slowly.
Questions about the PulseQ E?
Tell us your vehicle and your home electrical supply – we’ll help you choose.
Questions we often get
Is a charging cable included?
Yes, the PulseQ E has a tethered 5 m Type 2 charging cable. A version with 7.5 m is optionally available.
Is 11 kW enough for my electric car?
For most vehicles, yes – many electric cars charge at a maximum of 11 kW on AC anyway.
Do I need approval from the grid operator?
In Germany, the wallbox must be registered. Additional approval isn’t needed at 11 kW, only above 12 kW.
What’s the difference from the PulseQ AC Pro?
The PulseQ E charges at up to 11 kW and has a tethered cable. The PulseQ AC Pro charges at up to 22 kW and has a Type 2 socket for your own cable.
Can I mount the wallbox outdoors?
Yes, with IP65 protection and an operating range of -35 °C to 55 °C it’s suitable for carports and outside walls.
