OPDON PHOENIX ELITE Automotive Diagnostic Tool
1.589,00 €
TOPDON Phoenix Elite – professional automotive diagnostic scanner with Topology Mapping, ECU coding and bidirectional active tests.
- 10.1″ display, Android 10 and 2.0 GHz quad-core processor
- OE-level diagnostics with graphical control unit topology
- ECU coding, active tests and extensive service functions
- CAN FD, AutoVIN plus Pre-Scan and Post-Scan reports
Designed for professional workshops and advanced vehicle diagnostics.
- Description
- Jetzt kontaktieren
- Reviews (0)
Description
TOPDON Phoenix Elite – Professional Automotive Diagnostic Scanner for Workshops
The TOPDON Phoenix Elite is a professional automotive diagnostic scanner designed for demanding workshops and diagnostic specialists. Combining OE-level diagnostics, graphical Topology Mapping, ECU coding, active tests and extensive service functions, it provides a powerful platform for modern vehicle diagnostics.
| Model | TOPDON Phoenix Elite |
|---|---|
| Display | 10.1-inch LCD · 1280 × 800 |
| Processor | 4-Core · 2.0 GHz |
| Operating System | Android 10.0 |
| Topology | Graphical Topology Mapping |
| ECU Coding | Yes, depending on vehicle and control unit |
| Active Tests | Yes, bidirectional control on supported vehicles |
| CAN FD | Supported |
| Battery | 12,600 mAh |
Designed for Professional Vehicle Diagnostics
The TOPDON Phoenix Elite is designed for professional technicians, workshops and diagnostic specialists. Powerful hardware featuring a 2.0 GHz quad-core processor, Android 10 and a large 10.1-inch display provides a fast and clear diagnostic workflow.
In addition to comprehensive control unit diagnostics, functions such as online coding, cloud-based programming, active tests, initializations and adaptations are available depending on the vehicle and control unit.
Topology Mapping
Graphical visualization of vehicle control units and CAN networks provides a clear overview of the vehicle’s electronic architecture and helps technicians quickly identify communication and control unit issues.
AutoVIN & Scan
Automatic vehicle identification together with Pre-Scan and Post-Scan reports helps streamline diagnostics and provides useful documentation before and after repair work.
Guided Diagnostics
Guided diagnostic functions are available for supported Volkswagen, Audi, Škoda and SEAT vehicles.
ECU Coding & Advanced Diagnostic Functions
Depending on the vehicle, the TOPDON Phoenix Elite supports ECU coding, bidirectional active tests and additional advanced diagnostic functions.
Supported components and actuators can be commanded directly, allowing technicians to perform more targeted troubleshooting and isolate faults more efficiently. The graphical topology view also assists with analyzing communication between different vehicle control units.
Service, Reset & Special Functions
The TOPDON Phoenix Elite provides a wide range of maintenance, reset and special functions for professional workshop use.
- Oil service reset
- Brake reset
- DPF regeneration
- AdBlue reset
- Battery replacement initialization
- Steering angle sensor calibration
- Brake bleeding
- Throttle calibration
- TPMS functions
- Air conditioning initialization
- Airbag diagnostics
- EGR functions
- Injector coding
- Suspension calibration
- Air/fuel adaptation
- IMMO / key programming*
Available functions depend on the vehicle manufacturer, model, model year and installed control unit.
Active Tests & Bidirectional Control
With active tests, the TOPDON Phoenix Elite can directly command supported vehicle components and actuators through the corresponding control unit.
This allows technicians to test components directly and narrow down faults more efficiently instead of relying solely on fault codes and live data.
Available active tests and bidirectional functions depend on the vehicle and installed control units.
Optional ADAS Calibration Support
When combined with the Phoenix ADAS Mobile Package, the TOPDON Phoenix Elite can be used for calibration of supported advanced driver assistance systems.
TOPDON Phoenix Elite Technical Specifications
| Display | 10.1-inch LCD · 1280 × 800 |
|---|---|
| Processor | 4-Core · 2.0 GHz |
| Operating System | Android 10.0 |
| Battery | 12,600 mAh |
| Operating Voltage | 9–18 V |
| Operating Temperature | 0 °C to 50 °C |
| Storage Temperature | -20 °C to 60 °C |
| Dimensions | 278 × 191 × 48 mm |
| Languages | Multilingual – English, German, French, Spanish and more |
What’s Included
- 1× TOPDON Phoenix Elite
- 1× VCI Dongle
- 1× OBDI Adapter Box Transfer Cable
- 1× OBDII Extension Cable
- 1× Cigarette Lighter Cable
- 1× Type-C to USB Cable
- 1× Battery Clamp / Cable Set
- 1× Power Adapter
- 1× User Manual
- 1× Password Envelope
- 1× BMW F-Chassis Programming Cable
Is the TOPDON Phoenix Elite Compatible with Your Vehicle?
Diagnostic, ECU coding and special functions can vary depending on the vehicle, model year and control unit. Check vehicle coverage before purchasing.
